Product Introduction
635nm Industrial Powell Flat-Top Line Laser Module | High Uniformity Structured Light for Mass Production Precision Detection
3D structured light data acquisition & industrial workpiece contour reconstruction
Ultra-precision dimensional calibration & surface micro-defect inspection
AGV intelligent robot path navigation & automatic positioning correction
Automotive structural parts & welding seam quality inspection
Metallurgical slab dimension marking & thickness positioning calibration
Highway & rail track surface crack & damage intelligent inspection
Automated assembly auxiliary positioning & laboratory optical precision research
Technical Parameters
|
Parameter Item |
Specification |
|
Model |
Powell Lens Laser Module |
|
Wavelength |
635nm |
|
Wavelength Tolerance |
±5.0nm |
|
Output Power |
10mW,20mW,30mW,50mW,80mW,100mW,150mW,200mW,400mW |
|
Line Thickness (1/e² standard) |
10μm@30mm,20μm@50mm,30μm@80mm,40μm@100mm,70μm@200mm,100μm@300mm |
|
Fan Angles |
10°,20°,30°,45°,60°,75° |
|
Spatial Mode |
Single Transverse Mode, Multi Transverse Mode |
|
Line Straightness |
≤0.10% |
|
Relative Intensity Uniformity |
＞70% |
|
Laser Drive Modes |
CW, Analog Modulation, Digital Modulation, Computer Control |
|
Operating Voltage |
5.0VDC,9.0VDC,12.0VDC |
|
Operating Current |
<500mA |
|
Input Impedance |
＞1 kΩ |
|
Beam Divergence Angle |
<3.0 mrad |
|
ESD Protection Grade |
Level 4 |
|
Operating Temperature |
-20℃ ~ 60℃ |
|
Storage Temperature |
-40℃ ~ 85℃ |
|
MTBF |
> 10,000 Hours |
Adopting upgraded aspheric Powell beam shaping optical architecture, this line laser eliminates the inherent defects of traditional Gaussian laser such as central light overflow and edge brightness attenuation, achieving flat-top uniform energy distribution along the full laser line.
Its high-SNR flat light output stabilizes imaging performance of machine vision and 3D structured light scanning systems, drastically cutting misdetection and missing detection rates during continuous mass production, lifting finished product yield for manufacturers.
Its high-SNR flat light output stabilizes imaging performance of machine vision and 3D structured light scanning systems, drastically cutting misdetection and missing detection rates during continuous mass production, lifting finished product yield for manufacturers.
We provide one-stop full customization covering optical indicators and mechanical structures, including wavelength, output power, fan angle, micron-level line width precision and housing outline size. This complete customized solution saves enterprises independent optical R&D investment and shortens new equipment iteration cycle by nearly 40%.
The universal 5-24V wide voltage design matches mainstream factory power supply systems; multi-channel signal modulation can be directly connected to PLC, industrial cameras and automatic control units, lowering peripheral circuit design difficulty and overall machine cost.
Equipped with multi-layer circuit protection and wide temperature resistance, the module maintains stable continuous operation in complicated workshop environments. Ultra-long MTBF over 10,000 hours minimizes unplanned shutdown maintenance and cuts long-term spare part & operation expenses.
All finished laser modules go through multi-stage aging and stability verification before shipment, securing uniform batch quality. Stable mass delivery cycle and dedicated technical support help buyers avoid order delay risks and post-production equipment failure losses.
