Product Introduction
The 5-in-1 Laser Module integrates five laser channels into one compact optical module, providing a multi-function laser solution for different scanning and measurement requirements.
By combining multiple laser patterns and wavelengths in a single module, it helps simplify system design and provides flexible options for optical integration.
The compact structure, stable optical output and customizable configuration make it suitable for handheld scanners, portable inspection equipment and customized scanning systems.
Technical Parameters
| Laser Channels | 5-in-1 Laser Module |
| Wavelength | Customized |
| Laser Pattern | Single Line, Multi-Line Laser Patterns (Customizable) |
| Working Distance | Fixed / Customizable |
| Line Width | Customizable |
| Depth of Field | Customizable |
| Single Line Uniformity | Customized |
| Multi-Line Uniformity | Customized |
| Line Straightness | Customized |
| Operating Voltage | Customized |
| Drive Mode | ACC Constant Current Drive |
| Control Mode | PWM Control |
| PWM Frequency | 0-100kHz |
| Operating Temperature | Customized |
| Storage Temperature | Customized |
| Lifetime | 8000-10000h |
Product Features
Five-Channel Integration
Five laser channels are integrated into one module, providing multiple laser options while reducing system space and installation complexity.
Multi-Function Laser Configuration
Supports different laser patterns and optical combinations to meet various scanning and measurement requirements.
Stable Optical Performance
Optimized optical design provides uniform brightness distribution, stable projection and reliable operation.
Compact Integrated Design
The integrated structure simplifies system design and allows flexible installation in different equipment.
Applications
Handheld Scanners
01
3D Scanning Equipment
02
Portable Inspection Devices
03
Optical Measurement Systems
04
Customized Scanning Systems
05
Customization
Dershine Laser provides customized multi-channel laser solutions according to different application requirements.
Customization options include:
- Laser wavelength
- Laser pattern
- Number of channels
- Working distance
-
Optical configuration
-
Housing structure
