Product Introduction
The Blue Line Laser Module provides a stable and precise blue laser line for industrial positioning, measurement and inspection applications.
With optimized optical design and reliable laser output, the module generates a clear line projection for accurate alignment and surface measurement.
The compact structure and flexible configuration allow easy integration into machine vision systems, automation equipment and customized optical solutions.
Product Parameters
|
Item |
Specification |
|
Laser Type |
Blue Line Laser Module |
|
Wavelength |
405nm, 450nm (Customized) |
|
Output Power |
1-10mW / 10-500mW |
|
Working Distance |
Adjustable / Fixed / Customized |
|
Line Straightness |
≤0.1% |
|
Fan Angle |
5°~130° |
|
Operating Current |
10-90mA / 60-300mA |
|
Operating Voltage |
3-5V, 12V, 24V |
|
Control Function |
TTL Switch (Optional) |
|
Housing Material |
Copper, Aerospace Aluminum |
|
Operating Temperature |
-10~50℃ |
|
Storage Temperature |
-40~85℃ |
|
Lifetime |
≥10000h |
|
Accessories |
Industrial Bracket, Power Supply, Cable Extension |
Product Features
Precise Blue Laser Line Projection
The blue laser output provides a clear and stable line pattern for accurate positioning and measurement.
Stable Optical Performance
Optimized optical design ensures consistent laser intensity and reliable line projection during operation.
High Precision Application Support
The fine laser line output is suitable for applications requiring accurate visual positioning and inspection.
Flexible Integration Design
Compact housing and customizable configurations support integration into different industrial systems.
Applications
- Industrial Positioning
- Equipment Alignment
- Automation Machinery
- Cutting Machine Positioning
-
Measurement Equipment
