Product Introduction
The Wide Angle Line Laser Module is designed for applications requiring a wider laser projection range and large-area positioning reference.
With a wide fan angle optical design, the module generates an extended laser line for covering larger working areas and improving positioning visibility.
The compact structure and flexible configuration make it suitable for industrial equipment, automation systems and applications requiring wide-area laser marking.
Product Parameters
|
Item |
Specification |
|
Laser Type |
Wide Angle Line Laser Module |
|
Wavelength |
405nm, 450nm, 520nm, 635nm, 650nm |
|
Output Power |
1-10mW / 10-500mW |
|
Laser Pattern |
Line |
|
Working Distance |
Adjustable / Fixed / Customized |
|
Line Straightness |
≤0.1% |
|
Fan Angle |
5°~130° |
|
Operating Current |
10-90mA / 60-300mA |
|
Operating Voltage |
3-5V, 12V, 24V |
|
Control Function |
TTL Switch (Optional) |
|
Housing Material |
Copper, Aerospace Aluminum |
|
Operating Temperature |
-10~50℃ |
|
Storage Temperature |
-40~85℃ |
|
Lifetime |
≥10000h |
|
Accessories |
Industrial Bracket, Power Supply, Cable Extension |
Product Advantages
|
Advantage |
Description |
|
Wide Projection Range |
Covers larger working areas with extended laser lines |
|
Flexible Installation |
Suitable for different mounting distances and angles |
|
Stable Output |
Maintains consistent laser performance during operation |
|
Clear Positioning Reference |
Provides intuitive visual guidance |
|
Compact Design |
Easy integration into industrial equipment |
Product Features
Wide Angle Laser Projection
The wide fan angle design provides an extended laser line coverage area, reducing installation limitations in large working spaces.
Large Area Positioning
The projected laser line provides a clear reference mark for equipment positioning and operation guidance.
Stable Optical Output
Optimized optical components ensure stable laser intensity and consistent line projection during operation.
Flexible Installation
Different optical configurations support various mounting distances and application requirements.
Easy Equipment Integration
Compact housing design allows convenient integration into different industrial systems.
Applications
Industrial Positioning
Providing wide-range positioning references for industrial equipment.
01
Automation Machinery
Used as a visual guidance solution in automated systems.
02
Equipment Installation
Helping operators complete large-area alignment and adjustment.
03
Processing Equipment
Providing laser reference lines for cutting and processing operations.
04
Safety and Guidance Systems
Used for visible positioning and indication applications.
05
Product Advantages
|
Advantage |
Description |
|
Clear Visibility |
Provides an easy-to-recognize visible laser line for positioning |
|
Stable Output |
Ensures consistent optical performance during continuous operation |
|
Flexible Configuration |
Supports different wavelengths, power levels and optical designs |
|
Easy Integration |
Compact structure suitable for various equipment installations |
|
Long Service Life |
Designed for reliable industrial operation |
Customization Options
Dershine Laser provides customized wide angle line laser solutions according to different industrial positioning requirements.
Customization options include:
- Laser wavelength
- Output power
- Fan angle
- Working distance
-
Line width
-
Housing structure
-
Cable configuration
