Product Introduction

The 5-Line Structured Light Laser Module is designed for applications requiring multiple laser line projection and structured light patterns.

By projecting multiple precise laser lines, the module provides structured optical information for 3D measurement, positioning and surface analysis applications.

With stable optical output, compact design and flexible configuration options, it can be integrated into structured light systems, measurement equipment and customized industrial applications.

Technical Parameters

Item	Specification
Laser Type	5-Line Structured Light Laser Module
Laser Pattern	5 Parallel Lines
Wavelength	405nm, 450nm, 520nm, 635nm, 650nm (Customized)
Output Power	Customized
Number of Lines	5 Lines
Line Spacing	Customized
Working Distance	Customized
Fan Angle	Customized
Line Straightness	≤0.1%
Operating Voltage	3-5V, 12V, 24V
Drive Mode	ACC Constant Current
Control Mode	TTL / Analog / PWM (Optional)
Operating Temperature	-10~50℃
Lifetime	≥10000h

Product Advantages

Advantage	Description
Multi-Line Projection	Provides multiple laser lines for structured light applications
Stable Line Arrangement	Ensures accurate spacing and projection consistency
Flexible Configuration	Supports customized optical parameters
Compact Design	Easy integration into equipment
Reliable Performance	Suitable for long-term industrial operation

Product Features

5-Line Structured Light Projection

The module generates five parallel laser lines to provide structured optical patterns for measurement and positioning applications.

High Precision Line Arrangement

Optimized optical design ensures accurate line spacing and stable projection performance.

Stable Optical Output

High-quality laser components provide consistent brightness and reliable operation.

Compact Integration Design

Small-size housing design allows easy integration into different equipment systems.

Flexible Customization

Supports customization of wavelength, output power, line number, spacing and optical configuration.

Applications

3D Measurement Systems

Providing structured light patterns for depth information acquisition.

Industrial Positioning

Supporting accurate positioning and alignment applications.

Object Surface Measurement

Used for surface profile analysis and dimensional measurement.

Automation Equipment

Integrated into industrial systems requiring multi-line projection.

Customized Structured Light Systems

Providing flexible structured light solutions according to application requirements.

Customization Options

Dershine Laser provides customized structured light laser solutions according to different application requirements.

Customization options include:

Laser wavelength
Output power
Number of laser lines
Line spacing
Projection angle
Working distance
Housing structure
Cable configuration
