Product Introduction

The 9-Line Structured Light Laser Module is designed for applications requiring multi-line laser projection and structured light patterns.
By projecting nine precisely arranged laser lines, the module provides structured optical information for 3D measurement, positioning and surface analysis applications.
With stable optical output, accurate line arrangement and flexible customization options, it can be integrated into structured light systems, measurement equipment and customized industrial applications.

Technical Parameters

Item	Specification
Laser Type	9-Line Structured Light Laser Module
Laser Pattern	9 Parallel Lines
Wavelength	405nm, 450nm, 520nm, 635nm, 650nm (Customized)
Output Power	Customized
Number of Lines	9 Lines
Line Spacing	Customized
Working Distance	Customized
Projection Angle	Customized
Line Straightness	≤0.1%
Operating Voltage	3-5V, 12V, 24V
Drive Mode	ACC Constant Current
Control Mode	TTL / Analog / PWM (Optional)
Operating Temperature	-10~50℃
Lifetime	≥10000h

Product Advantages

Advantage	Description
Multi-Line Projection	Provides nine structured laser lines for measurement applications
Accurate Line Arrangement	Ensures consistent line spacing and projection quality
Stable Performance	Maintains reliable optical output during operation
Flexible Configuration	Supports customized optical parameters
Compact Design	Easy integration into industrial equipment

Product Features

9-Line Structured Light Projection

The module generates nine parallel laser lines to create structured light patterns for accurate measurement and positioning applications.

Precise Line Arrangement

Optimized optical design ensures accurate line spacing and stable projection performance.

Stable Optical Output

High-quality laser components provide consistent brightness and reliable long-term operation.

Compact Integration Design

Compact housing design allows easy installation into different structured light systems.

Flexible Customization

Supports customization of wavelength, output power, line number, line spacing and optical parameters.

Applications

3D Measurement Systems

Providing structured light patterns for depth information acquisition.

Industrial Positioning

Supporting accurate positioning and alignment applications.

Surface Profile Measurement

Used for surface shape analysis and dimensional measurement.

Automation Equipment

Integrated into industrial systems requiring multi-line laser projection.

Customized Structured Light Systems

Providing flexible solutions for different structured light applications.

Customization Options

Dershine Laser provides customized 9-line structured light laser solutions according to different application requirements.
Customization options include:

Laser wavelength
Output power
Number of laser lines
Line spacing
Projection angle
Working distance
Housing structure
Cable configuration
